Thermo-Roofs Shield: Advanced Thermal and Waterproof Coating
Transform your roofs and facades with Thermo-Cubiertas Shield, a high-performance coating designed to provide superior thermal insulation, waterproofing, and durability. Engineered with cutting-edge microsphere technology, this product reflects up to 93.9% of solar radiation, significantly reducing heat transfer and maintaining comfortable indoor temperatures. Whether you’re looking to protect your building from harsh weather or enhance energy efficiency, Thermo-Cubiertas Shield is the ultimate solution.
Key Features
- Exceptional Thermal Insulation: With a solar reflectance factor of 93.9% and a thermal conductivity of 0.05 W/m·K, it reduces heat flow by 73.84%, keeping interiors cooler.
- Robust Waterproofing: Highly permeable to water vapor (Class I) yet prevents liquid water penetration, ideal for roofs and facades.
- Long-Lasting Durability: Offers a 7-year guarantee with resistance to weathering, UV exposure, and 3000 cycles of artificial aging without cracking or peeling.
- Flexible Application: Suitable for various surfaces, with recommended consumption of 0.8-2 L/m² for roofs and 0.8-1.5 L/m² for facades.
- Acoustic Benefits: Provides sound absorption (αw = 0.10), enhancing indoor comfort.
- Fire Safety: Classified as M1 for fire reaction, ensuring safety in critical applications.
Why Choose Thermo-Cubiertas Shield?
Thermo-Cubiertas Shield is more than just a coating—it’s a comprehensive solution for modern construction challenges. Its high solid content (71%) and low viscosity (60,000 cps) ensure easy application with brushes, rollers, or spray equipment. The product’s microsphere size (≤28 μm) enhances its performance, while its ability to withstand 190% elongation makes it ideal for surfaces prone to cracking. Plus, it’s environmentally friendly, requiring only water for tool cleanup.
Application Guidelines
- Surface Preparation: Ensure the surface is clean, dry, and free of dust, mold, or loose paint. Treat mold with a bleach solution and apply Fungilev fungicide if needed. Use Suber-Fix primer on powdery surfaces and Thermal Putty for repairs.
- Mixing: Stir thoroughly, adding 8-15% clean water if necessary for consistency.
- Application: Apply 2-3 coats using a brush, roller, or spray, with a minimum drying time of 8-12 hours between coats. For horizontal surfaces or complex substrates, incorporate a 60-80 g/m² fiberglass mesh.
- Finishing: Apply 150 ml/m² of Suberlev Transitable Varnish for enhanced walkability and a 7-year warranty.
- Consumption: Roofs: 0.8-2 L/m² (2.5 L/m² for waterproofing); Facades: 0.8-1.5 L/m²; Thermal reflection: ≥0.6 L/m².
Technical Specifications
| Property | Value | Standard |
|---|---|---|
| Solar Reflectance | 93.9% | ASTM G173-03 |
| Emissivity | 0.75 | ASTM C1371-04a |
| Solar Reflectance Index (SRI) | 101.8–103.6 | ASTM E1980-11 |
| Heat Flow Reduction | 73.84% | – |
| Density | 1.1 kg/L ± 5% | – |
| Tensile Strength | 30 kg/cm² | – |
| Adhesion | 18.35 kg/cm² | EN 1504-2 |
| Water Vapor Permeability | Class I | UNE-EN 1062-3 |
Storage and Precautions
Store in a cool, dry place (5-45°C) for up to 2 years in its original container. Keep out of reach of children and prevent product buildup on container walls to avoid clogs during application. Available in 15L polypropylene buckets (white, with custom NCS colors on request).
Ideal For
- Residential and commercial roofs
- Exterior facades
- Buildings in extreme climates
- Energy-efficient construction projects
Certified Quality
Tested by leading laboratories (AIDICO, APPLUS, TECNALIA, AITEX) to ensure performance and reliability.
